Popis
These „KN“ Series wire wound Pt100 platinum sensing elements are available in three tolerance classes:
Class A, Temperature Range -100 to 450°C, Tolerance = ± 0.15+(.002 * t) °C
Class 1/3, Temperature Range -100 to 350°C, Tolerance = ± 0.10+(.0017 * t) °C
Class 1/10, Temperature Range 0 to 100°C, Tolerance = ± 1/10*( 0.30+(.005 * t)) °C
with t = temperature in °C regardless of sign.
Note: These Pt100 elements are capable of being exposed to temperatures between -196 and 600°C, however the tolerances apply only within the temperature ranges shown for each class.
These Pt100 elements are made with wire wound platinum coils, ceramic housings and palladium-gold alloy lead wires. The small size of the Pt100 sensor body allows for easy installation in protective tubes or custom housings. Pt100 applications include a variety of processes and equipment.
The online configurator may not contain all available options. If you do not find what you are looking for, please contact us.
Complete informations can be found in the spec sheet (PDF), see the „Download“ section.
